• Meets American Boat and Yacht Council (ABYC) standards
• UL 1077 recognized, TUV certified, CE Marked for Europe, and CSA certified for Canada
• The industry standard circuit breaker for Blue Sea Systems' electrical panels
• Combines swtiching and circuit protection into a single device
• "Trip Free" design cannot be held "ON" during fault current condition

Specifications

Trip Time Delay	See trip delay curve
Interrupt Rating	See interrupt rating table
Maximum Voltage Rating	See interrupt rating table
Operating Temperature Range	-40°C to +85°C
Terminal Screw	#10-32 SS with external tooth lock washer - Recommended torque 14-15 in-lb
Rated Switch Cycles	10,000 @ rated amperage and voltage
Mounting Screw	#8-32 - Recommended torque 6-8 in-lb
Circuit Breaker Type	Magnetic Hydraulic - trip free
Weight Lb (Kg)	0.17 (0.08)

Certifications & Agency Standards

• Marked
• TUV Certified
• CSA certified
• UL 1077 recognised

Interrupt Rating Table
