Max Power offers a complete range of 12V/24V electric tunnel thrusters to
suit motor boats and deep footed sailing yachts from 17’ to 85’ feet.
Designed for performance & durability, Max Power electric tunnel thrusters
offer many unique features:
- Corrosion free composite drive legs eliminate the need for periodic anode
changes and offer high manufacturing tolerances
- Drive legs are pre-filled with oil and sealed for life for zero
maintenance
- Case hardened spiro-conical gears guarantee a silent, smooth and durable
drive leg
- Line shields protect oil seals from fishing lines & fouling, ensuring
maintenance free operation
- High efficiency, purpose built DC motors ensure outstanding performance
and long runtime ratings
- Solid copper contact bars guarantee safe, high power connections
- Purpose built high specification DC contactors are both safe and durable
- Electronic control boxes offering unique and unrivaled safety features to
protect against accidental misuse
The CT45 is ideal for motor boats and deep footed sailing yachts ranging from
19’-36'. Manufactured using composite materials, the CT45 has a 125mm diameter
tunnel. As small and compact as the CT35, the CT45 benefits from an
increased thrust rating up to 40/88 (kg/lbs) thanks to its twin propellers.
Easy to install and maintenance free, this model integrates all the unique
features common to Max Power’s electric tunnel thrusters.
* Thrusters are designed to run at 10.75V on 12V units and 22V on 24V
units. Higher voltages will result in higher thrust ratings, higher power
consumption, and a reduced duty cycle.
* Performance data is given for a thruster installed at an immersion depth
of one tunnel’s diameter, in a tunnel no longer than twice the tunnel’s
diameter, and this within a variation of + / - 6%. Longer tunnels will
result in lower thrust ratings and higher power consumption.
| Code |
Voltage |
Thrust |
Propellers |
Power |
Weight |
A |
B |
C |
D |
E |
| 317603 |
12V |
30(kg) / 88(lbs) |
2 |
3.23(kw) / 4.3(hp) |
9.65(kg) |
190(mm) |
140(mm) |
210(mm) |
125(mm) |
4 - 5(mm) |
